Phù hợp cho: H3C ADP040-54V-PoE-GL là bộ cấp nguồn PoE một cổng gồm adapter và injector, ra 54 V – 40 W, đầu vào 90–264 VAC, có bảo vệ quá dòng, quá áp, ngắn mạch. Phù hợp cấp nguồn qua cáp Cat5e cho access point H3C trong nhà khi switch không có PoE. Nên đặt injector nơi khô ráo, trong nhà.
Thông số kỹ thuật Bộ nguồn Power Adapter H3C ADP040-54V-PoE-GL
- PoE Power Adapter H3C ADP040-54V-PoE-GL
- ADP040-54V-POE-GL is centralized network remote power adapter with single port, and designed for indoor wireless AP. Its Voltage input is from 90 to 264VAC. This adapter can connect to other network terminal equipment, such as wireless AP, with CAT5e cable, working for 10/100/1000M network scenarios.
- Size (L × W × H): Adapter: 110mm × 62mm × 31.5mm – Injector: 79mm × 70mm × 31mm
- Weight: 282g
- Input Voltage: 90V AC~264V AC; 47~63Hz
- Input Current: 1.5A Max, at 115Vac, Full load; 0.8A Max, at 230Vac, Full load
- Input Connector: IEC320 C14
- Output Voltage: 54V
- Output rated current: 0.74A
- Output Power: 40W
- Output Connection: Pins 4,5(+) Pins 7,8 (-)
- Power Efficiency: Level VI
- Protection: OCP, OVP, SCP
- Temperature: Operation: -10℃~45℃ – Non-operation: -40℃~70℃
- Humidity (Non-condensing): 5%~95%
- Altitude: Up to 5000m
- EMC: EN 55032: RE,CE; CISPR 32: RE,CE; IEC 61000-4-2: ESD; IEC 61000-4-3: RS; IEC 61000-4-4: EFT; IEC 61000-4-5: Surge; IEC 61000-4-6: CS; IEC 61000-4-11: DIPS
- Safety Approvals: CE,TUV,UL,CCC
